Optical
Throw Ratio
0.49
Zoom Ratio
Fixed
Lens Control
Manual Focus
Keystone Correction
1D, Vertical ± 30 degrees
Projection Size
70"~120"
Projection Offset
105±2.5%( (Full-Height)
Display
Projection System
DLP Single 0.65" WXGA
DMD type
DC3 DMD chip
Brightness
3,300 Lumens
Contrast Ratio*
20,000:1
Display Color
1.07 Billion Colors
Aspect Ratio
Native 16:10 (5 aspect ratio selectable)
Light Source
Lamp 200W
Native Resolution
1280x800 pixels, 16:10
Light Source life*
Normal 5000 hrs;Economic 10000 hrs;SmartEco 10000 hrs;LampSave 15000
hrs
hrs
Audio
Built-in Speaker
2W x1
Feature
Security
Security Bar, Kensington anti-theft lock slot
Feature
Built-In smart system, BenQ Launcher, Hidden Wireless dingle, Bluetooth
Audio out, HID Devices supported (e.g. Mouse, keyboard) Digital zoom
(2x), Digital Shrink(0.8x) and Shift, LAN Control, AMX/ PJ
Link/Crestron/MDA,DMS Local Compatibility, FW upgrade via LAN
Connectivity
HDMI
x 1
PC (D-sub 15pin)
x 1
Monitor out (D-sub 15pin,Female)
x 1
Audio in(mini jack)
x 1
Audio out (mini jack)
x 1
RS232 In (D-sub 9pin, male)
x 1
USB TypeA-1
x 1
USB TypeA-2 (5V,1.5A)
x 1
USB Type mini B
x 1
IR Receiver(Front+Top)
x 2
LAN Port(RJ45 for Network )
x 1
Compatibility
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200)
Horizontal Frequency
15~102 KHz
Vertical Scan Rate
23 ~ 120 Hz
HDTV Compatibility
480i, 480p, 576i, 567p, 720p, 1080i, 1080p
Video Compatibility
NTSC, PAL, SECAM
Power
Power Comsumption(Max/Normal/Eco)
Max 320W. Normal 280 W. Eco 235 W.
Standby Power Comsumption
Normal < 0.5Watts. Network < 2W.
Dimension and Weight
Product Dimensions (WxHxD)
296x 120x 250 mm
Product Weight
2.6 Kg+/- 200g
Accessories
Accessories (Standard)
Wireless Dongle: WDR02U Power Cord (by region) Remote Control w/
Battery
Battery
(RCI023) VGA cable Warranty Card (by region) QSG
Accessories (Optional)
Spare Lamp Kit (5J.JLT05.001) 3D Glasses (5J.J9H25.002) Wall mount
(WM06G3)
InstaShow Host
Power Supply
100 ~ 240V AC
Smart System
OS System
Android 6.0
ROM/RAM
16GB/2GB
Wireless
Wireless
Dual Band 802.11ac/b/g/n, 2.4G/5G
Bluetooth
4.0
